Technical Specification
Capacity: Up to 3 Mattresses per minute including compression
Film thickness: 80 - 150 micron
Printed film for brand promotion
Maximum roll width: upper 2500mm lower 2300mm
Maximum mattress/base size: 200 x 210 x 38 cm
Control: Motion controller
Power: 380 V. 3 Phase or customer specification
Air pressure: 6- Bar
Total area required : 3000 x 6000 mm
Full automatic operation capabilities and rapid rate of work
Servo controlled seal bars are self-adjusting for all bed sizes
High reliability of the sealing process with continuous heat seal bars
Compact design and compatible for integration with conveyors
Double seal bars, constant heat, PID controlled
Lower film magazine
Auto-recognition if product is a mattress or divan base
Applies polythene "boots" around end of mattress to save the need for cardboard corner protectors
